超聲波清洗機的機械清洗方法

Mechanical cleaning method of ultrasonic cleaning machine

1.手動清除方法手動方法? 使用金屬刷，刮刀和其他工具清除零件表麵的汙垢。 該方法還包括使用棉，絲綢，合成纖維產品和絨麵革擦拭零部件表麵以去除汙垢。

1. Manual method? Manual method? Use metal brushes, scrapers and other tools to remove dirt from the surface of parts. The method also includes wiping parts with cotton, silk, synthetic fiber products and suede to remove dirt.

2.機械工具的清潔方法使用電動或氣動工具驅動金屬刷，軟砂輪等，以清除零件表麵上的積碳，鐵鏽，油漆等。

2. Cleaning method of mechanical tools: use electric or pneumatic tools to drive metal brush, soft grinding wheel, etc. to remove carbon, rust, paint, etc. on the surface of parts.

3.壓縮空氣吹掃法使用壓縮空氣吹掃覆蓋零件的幹粉塵，油泥等。

3. Compressed air purging method uses compressed air to purge dry dust and oil sludge covering parts.

4.高壓水洗方法

4. High pressure water washing method

超聲波清洗機的標準保養方法

Standard maintenance method of ultrasonic cleaning machine

1：電源為AC 380v。 (三相四線)

1: The power supply is AC 380V. (three phase four wire)

2：首先將信號線連接在超聲波電源和清潔箱之間。 (複選標記連接)

2: First, connect the signal line between the ultrasonic power supply and the cleaning box. (check mark connection)

3：將液體倒入清洗槽中，高度約為300mm。 當儲液罐中的液體達到儲液罐高度的一半時，其溫度可達到40-55度。

3: Pour the liquid into the cleaning tank, about 300 mm high. When the liquid in the tank reaches half of the height of the tank, the temperature can reach 40-55 degrees.

4：將要清洗的工件放入清洗槽，並盡量不要直接接觸工件底部。 請勿撞擊清潔箱的側壁。

4: Put the workpiece to be cleaned into the cleaning tank, and try not to directly contact the bottom of the workpiece. Do not hit the side wall of the cleaning box.

5：設置超聲的工作時間(注意時間不能為零)，按超聲的開始按鈕，超聲開始工作。

5: Set the working time of ultrasound (note that the time cannot be zero), and press the start button of ultrasound to start working.

6：清潔時間取決於工件的油汙程度。

6: The cleaning time depends on the degree of oil contamination on the workpiece.

7：關閉循環過濾器時，請關閉過濾器出口閥。

7: When closing the circulating filter, please close the outlet valve of the filter.

8：定期清潔清潔槽底部的汙泥。

8: Clean the sludge at the bottom of the tank regularly.

9：如果在夏天長時間不使用設備(7天)，則應幹淨地排出清潔槽中的液體;在冬天，須確保清潔槽不會凍結。

9: If the equipment is not used for a long time in summer (7 days), the liquid in the cleaning tank should be drained clean; in winter, the cleaning tank must not be frozen.

10：如果車間灰塵較大，應每月使用壓縮空氣清潔配電櫃中的灰塵。

10: If the workshop is dusty, compressed air should be used to clean the dust in the distribution cabinet every month.

超聲波清洗機要長時間正常工作，注意其維護和日常維護工作非常重要。 除了避免不規則操作外，還須定期維護和維護清潔機並進行以下工作：

It is very important to pay attention to the maintenance and daily maintenance of the ultrasonic cleaning machine. In addition to avoiding irregular operation, it is also necessary to regularly maintain and maintain the cleaning machine and carry out the following work:

①定期清理儲存箱中被汙染的清潔液。

① Clean the contaminated cleaning solution in the storage tank regularly.

②讓油泵定期運轉一次，每次至少10分鍾。

② Let the oil pump run regularly for at least 10 minutes each time.

③洗衣機用完後，蓋上蓋子以防止灰塵和濕氣。

③ Cover the washing machine after use to prevent dust and moisture.

本期的精彩內容由山東超聲波清洗機的小編整理所得，感謝大家的閱讀，如果有什麽不對的地方，歡迎到我們的官網：http://www.ahfanglei.com，給我們留言評論，91污將會給您一個滿意的答複

Thanks for your reading. If there is anything wrong, please visit our website: http://www.ahfanglei.com Leave us a comment and we will give you a satisfactory reply
