隨著超聲波清洗機設備的應用範圍越來越廣泛，各種經過不斷完善和改進的清洗設備正在取代已麵市的老式設備，下麵多槽手動超聲波清洗機生產廠家來講講清洗機的主要部件及每個部件的基本作用。

With the application scope of ultrasonic cleaning machine equipment becoming more and more extensive, various cleaning equipment that has been constantly improved and improved are replacing the old equipment that has been put on the market. Now, the manufacturers of multi slot manual ultrasonic cleaning machine will talk about the main components of the cleaning machine and the basic functions of each component.

高壓泵

High pressure pump

高壓清洗機的核心是高壓泵，它們處於不可替代的位置。高壓泵用於增加水壓，將高壓水輸送到高壓水槍或噴嘴。這種泵可以移動或固定。容積式柱塞泵是保證給定泵速下流量恒定的常用泵。

The core of the high-pressure washer is the high-pressure pump, which is in an irreplaceable position. The high-pressure pump is used to increase the water pressure and deliver high-pressure water to the high-pressure water gun or nozzle. The pump can be moved or fixed. Positive displacement piston pump is a commonly used pump to ensure constant flow at a given pump speed.

高壓清洗機自誕生以來，一直麵臨著許多故障，但一般90%的故障不是由泵引起的。常見的故障是由部件或部件（如噴嘴）磨損引起的。

Since its birth, the high-pressure washer has been faced with many failures, but generally 90% of the failures are not caused by the pump. Common failures are caused by wear of components or parts (such as nozzles).

水泵進水不足是水泵早期故障的主要原因。不合適的進氣管不能使足夠的水進入泵內，造成氣蝕，氣蝕會導致混入水中的氣體發生小爆炸，造成超壓損壞和活塞表麵磨損。

Inadequate water inflow is the main reason for the early failure of the pump. Inappropriate intake pipe cannot make enough water enter the pump, causing cavitation, which will lead to small explosion of gas mixed in water, resulting in overpressure damage and piston surface wear.

曲軸箱

Crankcase

曲軸箱故障很少。如果保養正常，應在初次使用50小時後更換潤滑油，然後每500小時或每年更換一次，直到潤滑油乳化為止，這通常是由於溫度或油封泄漏引起的老化和變質引起的，如果軸箱中的油塞沒有加滿或油封被吸到B中，潤滑油就會發熱。Y真空。

Crankcase failures are rare. If the maintenance is normal, replace the lubricating oil after 50 hours of initial use, and then replace it every 500 hours or every year until the lubricating oil is emulsified. This is usually caused by aging and deterioration caused by temperature or oil seal leakage. If the oil plug in the axle box is not filled or the oil seal is sucked into B, the lubricating oil will heat up. Y Vacuum.

過濾元件

Filter element

好的入口過濾器是保護設備的廉價方法。灰塵、碎屑和沙子很容易損壞閥門和活塞。解決方法是使用60-100目濾布和適合水流的尺寸，並確保定期檢查。

A good inlet filter is a cheap way to protect equipment. Dust, debris, and sand can easily damage the valve and piston. The solution is to use 60-100 mesh filter cloth and size suitable for water flow, and ensure regular inspection.

減壓閥

Pressure relief valve

隻有當設備對高壓水敏感時，有時由於高壓水，清洗液吸入口不能工作。

Only when the equipment is sensitive to high-pressure water, sometimes due to high-pressure water, the detergent suction inlet cannot work.

壓力表

Pressure gauge

高壓清洗機應設置此表以顯示壓力變化。壓力表的校準範圍至少比高壓清洗機的大工作壓力高50%。當壓力波動較大時，應設置壓力調節器以準確顯示壓力讀數。壓力表提供一個重要的警告條件，用於監測噴嘴磨損和密封失效導致的減少，並避免將來更昂貴的維護。

The high-pressure washer shall be equipped with this gauge to display the pressure change. The calibration range of the pressure gauge shall be at least 50% higher than the large working pressure of the high-pressure washer. When the pressure fluctuates greatly, the pressure regulator shall be set to accurately display the pressure reading. The pressure gauge provides an important warning condition to monitor the reduction caused by nozzle wear and seal failure and avoid more expensive maintenance in the future.

泄壓閥（調壓閥）

Pressure relief valve (pressure regulating valve)

這是清洗機的主要安全部件，它保證了噴槍的自由使用和水通過係統的流動。如果噴槍沒有完全釋放，壓力將繼續上升直到發動機（汽油發動機或馬達）被損壞或泵、軟管或噴槍損壞。安全閥將全部或部分水流回水箱或進水口，以防止壓力上升。

This is the main safety component of the washer, which ensures the free use of the spray gun and the flow of water through the system. If the spray gun is not completely released, the pressure will continue to rise until the engine (gasoline engine or motor) is damaged or the pump, hose or spray gun is damaged. The safety valve will return all or part of the water to the water tank or water inlet to prevent the pressure from rising.

清洗機的主要部件及每個部件的基本作用問題的解答就到這裏了，其實還有幾個部件91污沒有介紹到，您有興趣就來網站留言www.ahfanglei.com谘詢吧！

This is the end of the main parts of the washer and the basic functions of each part. In fact, there are still several parts we haven't introduced. If you are interested, please leave a message on the website www.ahfanglei.com!
