通過式噴淋清洗機工作原理是通過高壓水噴淋衝擊工件表麵並結合清洗劑的化學去汙、除油、切水能力，從而使工件達到潔淨的目的。下麵來具體講講。

The working principle of the through type spray cleaning machine is to impact the surface of the workpiece by spraying high pressure water and combine the chemical decontamination, oil removal and water cutting capabilities of the cleaning agent to make the workpiece clean. Let's talk about it in detail.

1、自動輸送鏈：傳送不鏽鋼材質、鏈條傳動，連續通過式前進，確保清洗籃框平穩、精確運行。

1. Automatic conveyor chain: It is used to transmit stainless steel materials, chain drive, and continuously pass forward to ensure the smooth and accurate operation of the cleaning basket frame.

2、噴淋係統：噴淋清洗共兩套，一道采用藥劑噴淋清洗，二道采用噴淋漂洗，三道采用噴淋漂洗、四道采用噴淋漂洗，五道采用噴淋防鏽、內腔設噴管，噴管上設不鏽鋼噴嘴，上下噴淋管噴嘴間錯布置，使清洗工件全方麵在清洗區域確保工件清洗時無噴淋盲區，保證工件清洗的潔淨度。

2. Spray system: there are two sets of spray cleaning, one is chemical spray cleaning, the other is spray rinsing, the third is spray rinsing, the fourth is spray rinsing, the fifth is spray rust prevention, the inner chamber is equipped with spray pipes, the spray pipes are equipped with stainless steel nozzles, and the nozzles of the upper and lower spray pipes are arranged in a staggered way, so that the workpiece can be cleaned in all aspects in the cleaning area to ensure that there is no spray blind area during workpiece cleaning, and to ensure the cleanliness of workpiece cleaning.

3、除油裝置：由於前清洗工位的處理量較大，所以清洗液中的含油量較多，為了防止排水中含油量過大，此工位設有除油係統。

3. Oil removal device: because the treatment capacity of the front cleaning station is large, the oil content in the cleaning solution is large. To prevent excessive oil content in the drainage, the station is equipped with an oil removal system.

4、過濾循環係統：循環過濾槽內清洗劑，提高清洗效果。采用袋式過濾器。

4. Filtering and circulating system: circulating the cleaning agent in the filtering tank to improve the cleaning effect. Bag filter is used.

5、切水係統：切水腔內單獨排放到總排水管中，在進料和出料外設有隔離段，防止水霧互竄;前後部設可拆式檢修窗，以便於設備檢修和清理。

5. Shearing water system: the shearing water chamber is separately discharged into the main drain pipe, and an isolation section is set outside the feeding and discharging to prevent water mist from channeling; Removable access windows are set at the front and rear to facilitate equipment maintenance and cleaning.

6、抽氣係統：各個噴淋與風切段都在側麵開有抽氣孔連接主管，主管前端配置有除霧塔內裝拉西環，配備離心風機進行抽氣。

6. Air extraction system: each spraying and air cutting section is equipped with an air extraction hole at the side to connect the main pipe. The front end of the main pipe is equipped with a Rasi ring inside the demister and a centrifugal fan for air extraction.

簡答通過式噴淋清洗機的工藝流程這個內容就講解完畢了，您有需求就來91污網站www.ahfanglei.com留言谘詢或者直接聯係，為您提供良好的服務！

Briefly answer the technological process of the through type spray washer. This is the end of the explanation. If you need, please come to our website www.ahfanglei.com to leave a message or contact us directly to provide you with good service!
